Video link of AT-101 Harness Bundling Machine
Specification of AT-101 Harness Bundling Machine
-
Tape width: 2-40mm
-
Taping length: 0-600mm per second
-
Wire diameter: 0.1-40mm
-
Weight: 26kg
Installation of AT-101 Harness Bundling Machine
-
Place the harness taping machine to the working area.
-
Make sure the machine is horizontal before fixed.
-
Conect the power cabel with footswitch.
Operation of AT-101 Harness Bundling Machine
-
Put the tapes into the tape rack.
-
Turn on the machine with "ON/OFF" button.
-
Select an operation mode with "AUTO/MANU" button.
-
Set a required speed.
-
Rotational speed should be defined under AUTO mode.
